Product Highlights

• ±5.5° wide range automatic leveling. The instrument stops rotating and the laser flashes with a sound alert when out of leveling range, ensuring reliable operation.
• Can be used horizontally, providing a vertical reference plane and a horizontal laser line.
• TILT mode with imbalance alarm function stops rotation when the instrument is bumped, ensuring construction accuracy.
• Windproof mode sets low environmental sensitivity, ensuring stability in outdoor work.
• Gradient mode allows setting a slope on the X-axis while maintaining automatic leveling on the other axis.
• Accuracy self-calibration function.
• Remote control operation function.
• Can be mounted on a tripod with a 5/8″ thread.
• Various carefully designed accessories extend the instrument’s utility.
• Rainproof and dustproof.

Application Analysis

Best Applications:

• Civil engineering
• Ground paving
• Square construction
• Warehouse and factory construction
• Painting
• Exhibition decoration construction
• Lifting and handling
• Prefabrication projects
• Decoration installation projects
• Dry construction

Technical Data

• Light Source: Red light
• Wavelength: 635nm
• Leveling Method: Pendulum leveling
• Working Range: 600m
• Accuracy: ±0.075mm/m
• Vertical Scanning Function: Yes
• Dual-Axis Slope Scanning Function: No
• Adjustable Area Scanning and Angle Function: No
• Imbalance Alarm: Yes
• Windproof Function: Yes
• Area Masking Function: No
• Sleep Function: Yes
• Long-Distance Tracking Function: No
• Up Plumb Point: Yes
• Forced Rotation Mode: No
• Bidirectional Wireless Communication Function: No
• Line Format: H-V
• Automatic Leveling Range: ±5.5°
• IP Rating: IP66
• Weight: 2.4Kg
• Dimensions: 219×160×202mm
• Power Supply: 3 D alkaline batteries or optional rechargeable lithium battery pack
